Visio 500

Visio 500 is the new Full HD desktop magnifier for people with visual impairments. The main focus of our product-development was an optimal ergonomic design and intuitive usability. The screen is widely adjustable and allows the user to set it easily in the best individual position for a relaxed reading. The camera can be switched electrically in different positions, including mirror-viewing.

What makes the Visio 500 the perfekt solution for the professional environment:

  • Ergonomically optimized
  • Simple and intuitive handling
  • Full HD camera and screen
  • Monitor height, tilt and reading distance are easily adjustable
  • Newly designed reading table with switchable damping function
  • Modern design
  • Small footprint compared to traditional CCTV cameras
  • Superior quality made in Germany for vocational and private use

Innovative new reading table

A newly developed reading table with damping in the reading direction provides high comfort through “soft movement”. Vertically (y-direction) the table can be locked and the y-movement is carried out through the moving camera, controlled by pressure sensors in the table. This drastically saves deskspace and allows placing a PC-keyboard directly in front of the reading table – especially helpful for people using the Visio 500 split screen function with a connected PC.


Technical Data and Downloads

  • Magnification
    • 1,1x to 55x
  • Modes
    • Full color and 7 false colors switchable in high contrast mode
    • Image-Optimization
  • Monitor
    • 22” (55cm) screen size with LED backlight
    • Non-glare screen
    • Full HD resolution (1080p, 1920 x1080 pixels)
    • Operating panel integrated in Monitor
  • Adjustment of the Monitor
    • Height, Tilt and reading distance
    • Electrically released brakes
    • Integrated Split-Screen-Function
  • Camera
    • Full HD Camera (1080 p, 60 Hz)
    • 30x optical zoom
    • Continuous autofocus, (toggle on/off)
  • Camera Positions (switchable)
    • Top of Page
    • Writing position (vertical)
    • Reading position
    • Mirror Position
  • Reading Table
    • Standard function as x/y-table
    • Switchable damping function
    • Lockable in the y-direction, then only movable horizontally
    • Controlling the camera movement through pressure sensors on the reading table
  • Dimensions
    • 52 × 48 × 25 cm (20" x 18.5" x 9.5")
    • Approx. 13 kg (28.5 lbs)
  • Connector
    • HDMI in / Full HD HDMI out / Full HD
    • USB 3.0 (USB Video Class Device)
    • External Power Supply
    • Downloads
